Omschrijving
BOURNS - SRU1028-121Y - Power Inductor (SMD), 120 µH, 650 mA, Shielded, 700 mA
- Inductance: 120µH
- RMS Current (Irms): 650mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 700mA
- Product Range: -
- DC Resistance Max: 0.428ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 2.8mm
- External Length / Height: 10mm
- External Width: 10mm
- Inductor Type: Shielded Power Choke
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Q Factor: 18
- Q Test Frequency: 796kHz
- Resonant Frequency: 6MHz
- Self Resonant Frequency Min: 6MHz
- Test Frequency: 0.796MHz
