Omschrijving
BOURNS - SRU5028-330Y - Power Inductor (SMD), 33 µH, 800 mA, Shielded, 680 mA, 5.2mm x 5.2mm x 2.8mm
- Inductance: 33µH
- RMS Current (Irms): 800mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 680mA
- Product Range: -
- Power Inductor Case: 5.2mm x 5.2mm x 2.8mm
- DC Resistance Max: 0.203ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 2.8mm
- External Length / Height: 5.2mm
- External Width: 5.2mm
- Inductor Type: Shielded Power Choke
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Q Factor: 15
- Q Test Frequency: 2.52MHz
- Resonant Frequency: 16MHz
- Self Resonant Frequency Min: 16MHz
- Test Frequency: 2.52MHz
