SS-3GL13P Microswitch, Subminiature Omron

OMRONSKU:SS-3GL13P Bestelcode:8774625

Prijs:
Actie prijs€2,99

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (19 units)

Documenten en downloads

Omschrijving

OMRON - SS-3GL13P - Microswitch, Snap Action, Roller Lever, SPDT, Solder, 3 A, 30 VDC

  • Microswitch Type: Snap Action
  • Microswitch Actuator: Roller Lever
  • Contact Configuration: SPDT
  • Switch Terminals: Solder
  • Contact Current Max: 3A
  • Contact Voltage DC Nom: 30VDC
  • Product Range: SS-P Series
  • Contact Voltage AC Nom: 125VAC
  • Operating Force Max: 0.5N
  • Actuation Type: Roller Lever
  • Actuator Type: Roller Lever
  • Contact Current AC: 3A
  • Contact Current AC Max: 3A
  • Contact Current DC Max: 3A
  • Contact Resistance: 50mohm
  • Contact Voltage AC Max: 125V
  • Contact Voltage DC Max: 30V
  • Dielectric Strength VDC: 1000V
  • External Depth: 6.4mm
  • External Length / Height: 11mm
  • External Width: 19.8mm
  • Fixing Centres LxW: 9.5mm
  • IP / NEMA Rating: IP40
  • Insulation Resistance: 100Mohm
  • Operating Force: 0.5N
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -25°C
  • Switching Capacity: 3A @ 125V ac
