Omschrijving
- Cable Shielding: Unscreened
- No. of Cores: 3Core
- Wire Gauge: -
- Conductor Area CSA: 4mm²
- Reel Length (Imperial): 164ft
- Reel Length (Metric): 50m
- Jacket Colour: Transparent
- No. of Max Strands x Strand Size: -
- Conductor Material: Copper
- Jacket Material: PVC
- External Diameter: 15.5mm
- Voltage Rating: 500V
- Product Range: SY Series
- Bend Radius Min: 310mm
- Cable Type: SY
- Core Identification: Number Coded Black Cores + Green/Yellow
- Core-Earth / Core-Core Voltage Rating: 300/500 V
- Flexing Temperature Max: 80°C
- Flexing Temperature Min: -5°C
- Operating Temperature Max: 80°C
- Operating Temperature Min: -30°C
- Outer Diameter: 15.5mm
- Screen Type, Secondary: Galvanised Steel Wire Armour
- Secondary Insulation Colour: Transparent
- Secondary Insulation Material: PVC
- Test Voltage: 3000V
