T92P7D12-12 Relay, DPST-NO, 277VAC, 28VDC, 40A Potter&BRUMFIELD - Te Connectivity

POTTER&BRUMFIELD - TE CONNECTIVITYSKU:6-1393211-5 Bestelcode:1892037

Prijs:
Actie prijs€31,98

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (148 units)

Documenten en downloads

Omschrijving

POTTER&BRUMFIELD - TE CONNECTIVITY - 6-1393211-5 - General Purpose Relay, T92 Series, Power, Non Latching, DPST-NO, 12 VDC, 40 A

  • Contact Configuration: DPST-NO
  • Coil Voltage: 12VDC
  • Contact Current: 40A
  • Product Range: T92 Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 277VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 28VDC
  • Contact Material: Silver Cadmium Oxide
  • Coil Resistance: 86ohm
  • SVHC: Cadmium oxide (27-Jun-2018)
  • Approvals & Standards: CSA, UL, VDE
  • Coil Voltage VDC Nom: 12V
  • Contact Current Max: 30A
  • Contact Voltage AC Nom: 277V
  • Contact Voltage DC Nom: 28V
  • External Depth: 52.3mm
  • External Height: 30.7mm
  • External Width: 34.5mm
  • Nom Operating Power: 1.7W
  • Relay Type: Power
