T92S7A22-240 Relay, DPST-NO, 277VAC, 28VDC, 40A Potter&BRUMFIELD - Te Connectivity

POTTER&BRUMFIELD - TE CONNECTIVITYSKU:1393212-5 Bestelcode:1892044

Prijs:
Actie prijs€27,78

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (154 units)

Documenten en downloads

Omschrijving

POTTER&BRUMFIELD - TE CONNECTIVITY - 1393212-5 - General Purpose Relay, T92 Series, Power, Non Latching, DPST-NO, 240 VAC, 40 A

  • Contact Configuration: DPST-NO
  • Coil Voltage: 240VAC
  • Contact Current: 40A
  • Product Range: T92 Series
  • Relay Mounting: Panel
  • Coil Type: Non Latching
  • Contact Voltage VAC: 277VAC
  • Relay Terminals: Quick Connect
  • Contact Voltage VDC: 28VDC
  • Contact Material: Silver Cadmium Oxide
  • Coil Resistance: 3.8kohm
  • SVHC: Cadmium oxide (27-Jun-2018)
  • Approvals & Standards: CSA, UL, VDE
  • Coil Voltage VAC Nom: 240V
  • Contact Current Max: 30A
  • Contact Voltage AC Nom: 277V
  • Contact Voltage DC Nom: 28V
  • External Depth: 52.32mm
  • External Height: 30.73mm
  • External Width: 34.54mm
  • Nom Operating Power: 4VA
  • Relay Type: Power - General Purpose
