T9CP1A54-240 Relay, SPST-NO, 250VAC, 30A Te Connectivity

TE CONNECTIVITYSKU:1649341-2 Bestelcode:1629085

Prijs:
Actie prijs€13,33

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (882 units)

Documenten en downloads

Omschrijving

PHOENIX CONTACT - 1629085 - Sensor Connector, M23 PRO Series, M23, Female, 16 Signal + 2 Power + PE Positions

  • Contact Configuration: SPST-NO
  • Coil Voltage: 240VAC
  • Contact Current: 30A
  • Product Range: T9C Series
  • Relay Mounting: Panel
  • Coil Type: -
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Quick Connect
  • Contact Voltage VDC: -
  • Contact Material: Silver Tin Indium Oxide
  • Coil Resistance: 12kohm
  • SVHC: No SVHC (27-Jun-2018)
  • AC Coil Power: 1.6VA
  • Approval Category: UL Recognised
  • Case Material: Plastic
  • Coil Current: 6.67mA
  • Coil Voltage VAC Nom: 240V
  • Contact Current AC Max: 20A
  • Contact Current Max: 30A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 28V
  • Dielectric Voltage Coil to Contact: 2500V
  • Dielectric Voltage Contact to Contact: 1500V
  • External Depth: 27.4mm
  • External Height: 27.9mm
  • External Length / Height: 27.9mm
  • External Width: 32.3mm
  • Fixing Centres: 43.61mm
  • Insulation Resistance: 1000Mohm
  • Nom Operating Power: 1.6VA
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -40°C
  • Relay Type: Power
  • Type: Dust protected
  • Voltage Rating VAC: 250VAC
