Omschrijving
PHOENIX CONTACT - 1629092 - Sensor Connector, M23 PRO Series, M23, Male, 7 Positions, Crimp Pin - Contacts Not Supplied
- Contact Configuration: SPDT
- Coil Voltage: 240VAC
- Contact Current: 20A
- Product Range: T9C Series
- Relay Mounting: Panel
- Coil Type: -
- Contact Voltage VAC: 250VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: -
- Contact Material: Silver Tin Indium Oxide
- Coil Resistance: 12kohm
- SVHC: No SVHC (27-Jun-2018)
- AC Coil Power: 1.6VA
- Approval Category: UL Recognised
- Case Material: Plastic
- Coil Current: 6.67mA
- Coil Voltage VAC Nom: 240V
- Contact Current AC Max: 20A
- Contact Current Max: 30A
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 28V
- Dielectric Voltage Coil to Contact: 2500V
- Dielectric Voltage Contact to Contact: 1500V
- External Depth: 27.4mm
- External Height: 27.9mm
- External Length / Height: 27.9mm
- External Width: 32.3mm
- Fixing Centres: 43.61mm
- Insulation Resistance: 1000Mohm
- Nom Operating Power: 1.6VA
- Operating Temperature Max: 70°C
- Operating Temperature Min: -40°C
- Relay Type: Power
- Type: Dust protected
- Voltage Rating VAC: 250VAC
