TRACO POWER - TDN 5-0921WISM - Isolated Surface Mount DC/DC Converter, ITE, 3:1, 5 W, 2 Output, 5 V, 500 mA
- No. of Outputs: 2 Output
- Output Power Max: 5W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 500mA
- Output Voltage - Output 2: -5V
- Output Current - Output 2: 500mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TDN 5WISM Series
- Input Voltage DC Min: 4.5V
- Input Voltage DC Max: 13.2V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: Surface Mount DIP
- DC / DC Converter Mounting: Surface Mount Device
- Width: 9.1mm
- Height: 10.2mm
- Depth: 13.2mm
- SVHC: No SVHC (27-Jun-2018)
- Approvals & Standards: EN, UL
