Tel 2-0521 Converter, DC-DC, +/-5V, 2W TRACO Power

TRACO POWERSKU:TEL 2-0521 Bestelcode:1007027

Prijs:
Actie prijs€20,20

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Nog maar 3 producten leverbaar

Documenten en downloads

Omschrijving

TRACO POWER - TEL 2-0521 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 2 W, 2 Output, 5 V, 200 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 2W
  • Output Voltage - Output 1: 5V
  • Output Current - Output 1: 200mA
  • Output Voltage - Output 2: -5V
  • Output Current - Output 2: 200mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TEL 15 Series
  • Input Voltage DC Min: 4.5V
  • Input Voltage DC Max: 9V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 13.7mm
  • Height: 7.2mm
  • Depth: 23.8mm
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CSA, cUL, EN, IEC, UL
  • Approvals & Standards: CSA, IEC, UL
  • Isolation Voltage: 1.5kV
  • No. of Outputs: 2Outputs
