TRACO POWER - TEL 5-1222 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 5 W, 2 Output, 12 V, 250 mA
- No. of Outputs: 2 Output
- Output Power Max: 5W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 250mA
- Output Voltage - Output 2: -12V
- Output Current - Output 2: 250mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TEL 5 Series
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 18V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.3mm
- Height: 10.2mm
- Depth: 32mm
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: CSA, EN, IEC, UL
- Approvals & Standards: CSA, IEC, UL
- Efficiency Max: 84%
- External Depth: 20.3mm
- External Length / Height: 10.2mm
- External Width: 32mm
- Isolation Voltage: 1.5kV
- Line Regulation: 0.3%
- Load Regulation: 2%
- No. of Outputs: 2Outputs
- Operating Temperature Max: 71°C
- Operating Temperature Min: -25°C
- Output Ripple Voltage pk-pk: 75mV
- Output Voltage +: 12VDC
- Output Voltage -: -12VDC
- Power Rating: 5W
- Supply Voltage: 12V
