Tel 5-1223 Converter, DC/DC, 5W, +/-15V TRACO Power

TRACO POWERSKU:TEL 5-1223 Bestelcode:1204972

Prijs:
Actie prijs€29,92

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (64 units)

Documenten en downloads

Omschrijving

TRACO POWER - TEL 5-1223 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 5 W, 2 Output, 15 V, 200 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 5W
  • Output Voltage - Output 1: 15V
  • Output Current - Output 1: 200mA
  • Output Voltage - Output 2: -15V
  • Output Current - Output 2: 200mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TEL-5 Series
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 18V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 20.3mm
  • Height: 10.2mm
  • Depth: 32mm
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CSA, EN, IEC, UL
  • Approvals & Standards: CSA, IEC, UL
  • Efficiency Max: 84%
  • External Depth: 20.3mm
  • External Length / Height: 10.2mm
  • External Width: 32mm
  • Isolation Voltage: 1.5kV
  • Line Regulation: 0.3%
  • Load Regulation: 2%
  • No. of Outputs: 2Outputs
  • Operating Temperature Max: 71°C
  • Operating Temperature Min: -25°C
  • Output Ripple Voltage pk-pk: 75mV
  • Output Voltage +: 15VDC
  • Output Voltage -: -15VDC
  • Power Rating: 5W
  • Supply Voltage: 12V
