TRACO POWER - TEN 5-4812WI - Isolated Through Hole DC/DC Converter, ITE, 4:1, 5 W, 1 Output, 12 V, 500 mA
- No. of Outputs: 1 Output
- Output Power Max: 5W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 500mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 75V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.3mm
- Height: 10.2mm
- Depth: 31.8mm
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: EN 60950, IEC 60950, UL/cUL 60950
- Approvals & Standards: IEC, UL
- Isolation Voltage: 1.5kV
- No. of Outputs: 1Outputs
