TRACO POWER - TES 5-2412 - Isolated Surface Mount DC/DC Converter, ITE, 2:1, 5 W, 1 Output, 12 V, 420 mA
- No. of Outputs: 1 Output
- Output Power Max: 5W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 420mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: Surface Mount DIP
- DC / DC Converter Mounting: Surface Mount Device
- Width: 20.6mm
- Height: 10.2mm
- Depth: 33.4mm
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: CSA, EN, IEC, UL
- Approvals & Standards: CSA, IEC, UL
- Efficiency: 85%
- External Depth: 20.6mm
- External Length / Height: 10.2mm
- External Width: 33.4mm
- Flammability Rating: UL94V-0
- Isolation Voltage: 1.5kV
- Line Regulation: 0.3%
- Load Regulation: 1%
- Multiple Output Voltages: 12.00
- No. of Outputs: 1Outputs
- Operating Temperature Max: +85°C
- Operating Temperature Min: -40°C
- Output Voltage Max: 12V
- Power Rating: 5W
- Standard: UL 60950-1, IEC 60950-1, EN 60950-1
- Weight: 14g
