TRACO POWER - THD 12-2423WI - Isolated Through Hole DC/DC Converter, ITE, 4:1, 12 W, 2 Output, 15 V, 400 mA
- No. of Outputs: 2 Output
- Output Power Max: 12W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 400mA
- Output Voltage - Output 2: -15V
- Output Current - Output 2: 400mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: THD12WI Series
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.3mm
- Height: 10.2mm
- Depth: 32mm
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: EN 60950-1, IEC 60950-1, UL 60950-1
- Approvals & Standards: IEC, UL
- No. of Outputs: 2Outputs
