Omschrijving
TRACO POWER - TMV 2-2409SHI - Isolated Through Hole DC/DC Converter, Gate Drive, 1:1, 2 W, 1 Output, 9 V, 222 mA
- No. of Outputs: 1 Output
- Output Power Max: 2W
- Output Voltage - Output 1: 9V
- Output Current - Output 1: 222mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TMV 2HI Series
- Input Voltage DC Min: 21.6V
- Input Voltage DC Max: 26.4V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 7.5mm
- Height: 10.2mm
- Depth: 19.5mm
- SVHC: No SVHC (27-Jun-2018)
- Approvals & Standards: CAN, CSA, EN, IEC, UL
