TQ2-12V RELAY, SIGNAL, DPDT, 30VDC, 1A PANASONIC

PANASONICSKU:TQ2-12V Bestelcode:1200949

Prijs:
Actie prijs€5,57

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (12077 units)

Documenten en downloads

Omschrijving

PANASONIC - TQ2-12V - Signal Relay, 12 VDC, DPDT, 1 A, TQ, Through Hole, Non Latching

  • Coil Voltage: 12VDC
  • Contact Configuration: DPDT
  • Contact Current: 1A
  • Product Range: TQ Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: -
  • Contact Voltage VDC: 30V
  • Contact Material: Gold
  • Coil Resistance: 1.028kohm
  • SVHC: No SVHC (07-Jul-2017)
  • Approvals & Standards: CSA, UL
  • Coil Current: 11.7mA
  • Coil Operating Lower Percent Limit: 75%
  • Coil Operating Upper Percent Limit: 130%
  • Coil Power Continuous: 140mW
  • Coil Voltage VDC Nom: 12V
  • Contact Current AC Max: 0.5A
  • Contact Current DC Max: 0.1A
  • Contact Current Max: 1A
  • Contact Current Min: 10µA
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Nom: 30V
  • External Depth: 4.75mm
  • External Height: 14mm
  • External Width: 9mm
  • Lead Spacing: 2.54mm
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -40°C
  • Operating Time: 4ms
  • Relay Type: General Purpose
  • Release Time: 4ms
