Omschrijving
TRACO POWER - TVN 5-0925WI - Isolated Through Hole DC/DC Converter, ITE, 3:1, 5 W, 2 Output, 24 V, 104 mA
- No. of Outputs: 2 Output
- Output Power Max: 5W
- Output Voltage - Output 1: 24V
- Output Current - Output 1: 104mA
- Output Voltage - Output 2: -24V
- Output Current - Output 2: 104mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TVN 5WI Series
- Input Voltage DC Min: 4.5V
- Input Voltage DC Max: 12V
- DC / DC Converter Output Type: Fixed, Adjustable
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20mm
- Height: 10.2mm
- Depth: 32mm
- SVHC: No SVHC (27-Jun-2018)
- Approvals & Standards: EN, IEC, UL
