U.FL-R-SMT(01) RF Coaxial, U.FL, Straight Jack, 50ohm Hirose(Hrs)

HIROSE(HRS)SKU:U.FL-R-SMT(01) Bestelcode:3908021

Prijs:
Actie prijs€2,76

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (13424 units)

Documenten en downloads

Omschrijving

HIROSE(HRS) - U.FL-R-SMT(01) - RF / Coaxial Connector, U.FL Coaxial, Straight Jack, Solder, 50 ohm, Phosphor Bronze

  • Connector Type: U.FL Coaxial
  • Connector Body Style: Straight Jack
  • Coaxial Termination: Solder
  • Impedance: 50ohm
  • Coaxial Cable Types: -
  • Contact Material: Phosphor Bronze
  • Contact Plating: Gold Plated Contacts
  • Frequency Max: 6GHz
  • Connector Mounting: PCB Mount
  • Product Range: U.FL Series
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Category: UL 94V-0
  • Body Plating: Silver
  • Centre Contact Resistance: 25mohm
  • Connector Mounting Orientation: PC Board
  • Contact Resistance: 10mohm
  • External Length / Height: 2.5mm
  • Female Contact Material: Phosphor Bronze
  • Female Contact Plating: Gold
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 500Mohm
  • Male Contact Material: Brass
  • Male Contact Plating: Gold
  • Material: Phosphor Bronze
  • Operating Frequency Max: 6GHz
  • Operating Temperature Max: 90°C
  • Operating Temperature Min: -40°C
  • Outer Contact Resistance: 10mohm
  • Secondary Insulation Material: PBT
  • Termination Method: Solder
  • VSWR: 1.3
  • Voltage Rating VAC: 60V
