UPM1J102MHD Cap, 1000µF, 63V, 20% NICHICON

NICHICONSKU:UPM1J102MHD Bestelcode:8812705

Prijs:
Actie prijs€4,71

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (999 units)

Documenten en downloads

Omschrijving

NICHICON - UPM1J102MHD - Electrolytic Capacitor, 1000 µF, 63 V, ± 20%, Radial Leaded, 5000 hours @ 105°C, Polar

  • Capacitance: 1000µF
  • Voltage Rating: 63V
  • Product Range: PM Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 16mm
  • Lead Spacing: 7.5mm
  • Height: 40mm
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 5000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 40mm
  • Impedance: 0.027ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.8mm
  • No. of Pins: 2Pins
  • Operating Life Temperature: 105°C
  • Operating Temperature Range: -55°C to +105°C
  • Operating life Time: 9999h
  • Ripple Current AC: 2050mA
  • Ripple Current Frequency: 120Hz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 63V
