Omschrijving
SOURIAU-SUNBANK / EATON - UTS6JC106S - Circular Connector, Souriau Trim Trio UTS Series, Straight Plug, 6 Contacts
- Product Range: Trim Trio UTS Series
- Circular Connector Shell Style: Straight Plug
- No. of Contacts: 6Contacts
- Circular Contact Type: Crimp Socket - Contacts Not Supplied
- Coupling Style: Bayonet
- Connector Body Material: Thermoplastic Body
- Connector Body Plating: -
- Contact Material: -
- Contact Plating: -
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: UL, VDE
- Body Diameter: 26.2mm
- Cable Diameter Max: 8mm
- Cable Diameter Min: 1.5mm
- Colour: Black
- Connector Mounting: Cable Mount
- Connector Shell Size: 10
- Connector Type: Circular Industrial
- Contact Gender: Socket
- Flammability Rating: UL94V-0
- Gender: Plug
- IP / NEMA Rating: IP68, IP69K
- Insert Arrangement: 10-6
- Insulation Resistance: 5000Mohm
- No. of Mating Cycles: 250
- No. of Positions: 6Ways
- Operating Temperature Max: +105°C
- Operating Temperature Min: -40°C
- Test Voltage: 2000V
