XKA20420 Relay, DIN Rail, 4A Celduc

CELDUCSKU:XKA20420 Bestelcode:3822552

Prijs:
Actie prijs€69,98

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Nog maar 1 product leverbaar

Documenten en downloads

Omschrijving

CELDUC - XKA20420 - Solid State Relay, 4 A, 275 Vrms, DIN Rail, Screw, Zero Crossing

  • Contact Configuration: -
  • Load Current: 4A
  • Operating Voltage Max: 275Vrms
  • Relay Mounting: DIN Rail
  • Relay Terminals: Screw
  • Switching Mode: Zero Crossing
  • Operating Voltage Min: 12Vrms
  • Control Voltage Min: 6VDC
  • Control Voltage Max: 30VDC
  • Product Range: -
  • SVHC: No SVHC (07-Jul-2017)
  • Control Voltage DC Max: 30VDC
  • Control Voltage DC Min: 6VDC
  • Control Voltage Range: 6V DC to 30V DC
  • Control Voltage Type: DC
  • Current Rating: 4A
  • External Width: 11.5mm
  • Input Voltage Max: 280VAC
  • Input Voltage Min: 12VAC
  • Load Current Min: 5mA
  • Load Current RMS Max: 4A
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -40°C
  • Operating Voltage Range: 12Vrms to 275Vrms
  • Output Type: Triac
  • Peak Surge Current: 100A
  • RMS Load Current Min: 5mA
  • RMS Load Voltage Max: 275VAC
  • RMS Load Voltage Min: 12VAC
