35ZLG150MEFC8X11.5 Cap, 150µF, 35V, 20% RUBYCON

RUBYCONUGS :35ZLG150MEFC8X11.5 Code de commande:1281819

Prix:
Prix ​​promotionnel€0,49

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (3830 unité)

Documents et téléchargements

description

RUBYCON - 35ZLG150MEFC8X11.5 - Electrolytic Capacitor, Miniature, 150 µF, 35 V, ± 20%, Radial Leaded, 3000 hours @ 105°C, Polar

  • Capacitance: 150µF
  • Voltage Rating: 35V
  • Product Range: ZLG Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 8mm
  • Lead Spacing: 3.5mm
  • Height: 11.5mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 3000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 11.5mm
  • Frequency Tolerance: 120Hz
  • Impedance: 0.036ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.6mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +105°C
  • Operating life Time: 3000h
  • Ripple Current AC: 1000mA
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Tolerance Temperature: 20°C
  • Voltage Rating V DC: 35V
  • Voltage Rating VAC: 35V
