561R10TCCQ30 Cap, 30PF, 1 kV, 5%, C0G/NP0 Vishay

VISHAYUGS :561R10TCCQ30 Code de commande:1692265

Prix:
Prix ​​promotionnel€2,00

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (2549 unité)

Documents et téléchargements

description

VISHAY - 561R10TCCQ30 - Ceramic Disc Capacitor, 30 pF, 1 kV, ± 5%, C0G / NP0, 6.4 mm, Radial Leaded

  • Capacitance: 30pF
  • Voltage Rating: 1kV
  • Product Range: 561R Series
  • Capacitance Tolerance: ± 5%
  • Dielectric Characteristic: C0G / NP0
  • Lead Spacing: 6.4mm
  • Capacitor Terminals: Radial Leaded
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • SVHC: No SVHC (15-Jan-2019)
  • Body Diameter: 9.4mm
  • Capacitance Tolerance ±: ± 5%
  • External Depth: 4mm
  • External Length / Height: 41.4mm
  • External Width: 9.4mm
  • Lead Diameter: 0.6mm
  • Lead Length: 29mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -55°C to +105°C
  • Temperature Coefficient: 0ppm/°C ± 30ppm/°C
  • Voltage Rating V DC: 1000V
