GRAYHILL - 76SD01T - DIP / SIP Switch, 1 Circuits, Rocker, Through Hole, DPDT, 30 VDC, 150 mA
- No. of Circuits: 1Circuits
- Switch Actuator Style: Rocker
- Switch Mounting: Through Hole
- Contact Configuration: DPDT
- Contact Voltage DC Max: 30VDC
- Contact Current DC Max: 150mA
- Product Range: 76 Series
- Switch Type: DIP Unsealed
- SVHC: No SVHC (27-Jun-2018)
- Actuation Type: Raised
- Actuator Type: Raised Rocker
- Capacitance: 2pF
- Contact Resistance: 100mohm
- External Depth: 9.65mm
- External Length / Height: 7.49mm
- External Width: 9.7mm
- Lead Spacing: 2.54mm
- No. of Electrical Operations: 2000
- No. of Mechanical Operations: 2000
- No. of Positions: 1Ways
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Pitch Spacing: 2.54mm
- Storage Temperature Max: 85°C
- Storage Temperature Min: -55°C
