description
- No. of Outputs: 1 Output
- Power Rating (Covection Cooling): 55W
- Power Rating (Forced Cooling): 125W @ 10CFM
- Input Voltage VAC: 85V AC to 264V AC
- Power Supply Output Type: Adjustable, Fixed
- Output Voltage - Output 1: 24V
- Output Current - Output 1: 5.2A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Output Voltage - Output 4: -
- Current, Output 4: -
- Product Range: CLC125 Series
- SVHC: No SVHC (15-Jan-2018)
- Applications: General Purpose
- Approval Bodies: CB, CSA, EN, IEC, UL
- Height: 31.8mm
- Input Frequency: 63Hz
- Input Voltage: 85V AC to 264V AC
- Input Voltage AC Max: 264V
- Input Voltage AC Min: 85V
- Length: 101.6mm
- No. of Outputs: 1Outputs
- Output Current Max: 5.2A
- Output Power Max: 55W
- Power Rating: 125W
- Power Supply Type: Open Frame
- Width: 50.8mm
