C&K COMPONENTS - D6R30LFS - Tactile Switch, D6, Top Actuated, Through Hole, Round Button, 130 gf, 100mA at 32VDC
- Product Range: D6 Series
- Actuator Orientation: Top Actuated
- Switch Mounting: Through Hole
- Actuator Style: Round Button
- Actuating Force: 130gf
- Contact Rating: 100mA at 32VDC
- Switch Dimensions (L x W): 12mm x 11.4mm
- IP Rating: -
- Illumination: Non Illuminated
- SVHC: No SVHC (15-Jan-2019)
- Actuation Type: Top
- Actuator / Cap Colour: Yellow
- Colour: Yellow
- Contact Configuration: SPST-NO
- Contact Current DC Max: 100mA
- Contact Current Max: 100mA
- Contact Current Rating: 100mA
- Contact Resistance: 100mohm
- Contact Voltage AC Max: 100V
- Contact Voltage DC Max: 32V
- Contact Voltage DC Nom: 32V
- External Diameter: 12mm
- External Length / Height: 14.5mm
- External Width: 11.4mm
- Insulation Resistance: 100000Mohm
- Lead Spacing: 5mm
- No. of Mechanical Operations: 250000
- Operating Force: 1.3N
- Operating Temperature Max: 85°C
- Operating Temperature Min: -20°C
- Operating Time: 3ms
- Row Pitch: 5mm
- Stroke Length Max: 0.8mm
- Switch Operation: Off-(On)
- Switch Terminals: Solder
