PANASONIC - ECA0JHG682 - Electrolytic Capacitor, 6800 µF, 6.3 V, ± 20%, Radial Leaded, 1000 hours @ 105°C, Polar
- Capacitance: 6800µF
- Voltage Rating: 6.3V
- Product Range: -
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 12.5mm
- Lead Spacing: 5mm
- Height: 25mm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 1000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: AEC-Q200
- SVHC: No SVHC (07-Jul-2017)
- Capacitance Tolerance ±: ± 20%
- Lead Diameter: 0.6mm
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +105°C
- Ripple Current AC: 1350mA
