EEEHB1H100P Cap, 10µF, 50V, Radial, SMD Panasonic

PANASONICUGS :EEEHB1H100P Code de commande:9696873

Prix:
Prix ​​promotionnel€0,49

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1303 unité)

Documents et téléchargements

description

PANASONIC - EEEHB1H100P - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 10 µF, 50 V, 2000 hours @ 105°C, Polar

  • AE Capacitor Case: Radial Can - SMD
  • Capacitance: 10µF
  • Voltage Rating: 50V
  • ESR: -
  • Product Range: HB Series
  • Lifetime @ Temperature: 2000 hours @ 105°C
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Ripple Current AC: 35mA
  • Diameter: 6.3mm
  • Height: 5.8mm
  • Automotive Qualification Standard: AEC-Q200
  • MSL: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance: ± 20%
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Case Style: Radial Can - SMD
  • External Depth: 6.6mm
  • External Length / Height: 5.8mm
  • External Width: 6.6mm
  • Lead Cross-section Width: 0.65mm
  • Leakage Current: 3µA
  • Operating Temperature Range: -40°C to +105°C
  • Operating life Time: 2000h
  • Power Factor: 0.12
  • Power Factor Frequency: 120Hz
  • Tape Width: 16mm
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 50V
