PANASONIC - EEUFR1E152B - Electrolytic Capacitor, 1500 µF, 25 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar
- Capacitance: 1500µF
- Voltage Rating: 25V
- Product Range: FR Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 12.5mm
- Lead Spacing: 5mm
- Height: 20mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 10000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 20%
- Impedance: 0.018ohm
- Impedance Frequency: 100kHz
- Impedance Temperature: 20°C
- Lead Diameter: 0.6mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +105°C
- Ripple Current AC: 2600mA
- Ripple Current Frequency: 100kHz
- Ripple Current Temperature: 105°C
