FDB-25SBL2T2/1-LF Socket, D, Filtered, Pcb, 25WAY Cinch Connectivity Solutions

CINCH CONNECTIVITY SOLUTIONSUGS :FDB-25SBL2T2/1-LF Code de commande:1114161

Prix:
Prix ​​promotionnel€30,30

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (288 unité)

Documents et téléchargements

description

CINCH CONNECTIVITY SOLUTIONS - FDB-25SBL2T2/1-LF - D Sub Connector, Filtered, Receptacle, Cinch - FD, 25 Contacts, DB, Solder

  • Product Range: Cinch - FD Series
  • D Sub Shell Size: DB
  • Gender: Receptacle
  • No. of Contacts: 25Contacts
  • Capacitance: 1000pF
  • Connector Body Material: Steel Body
  • Contact Termination Type: Solder
  • Contact Material: Copper Alloy
  • Contact Plating: Gold over Nickel Plated Contacts
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: BS, HE, MIL Spec
  • Body Plating: Rear
  • Case Material: Steel
  • Connector Mounting: Through Hole Mount
  • Contact Resistance: 5mohm
  • Contact Termination: Solder
  • D Sub Connector Type: Filtered
  • DC Current Max: 5A
  • Insulation Resistance: 5000Mohm
  • No. of Mating Cycles: 250
  • Nominal Capacitance: 1mF
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -55°C
  • Working Voltage: 200V
