OMRON - G6SU-2 DC3 - Signal Relay, 3 VDC, DPDT, 2 A, G6S, Through Hole, Latching Single Coil
- Coil Voltage: 3VDC
- Contact Configuration: DPDT
- Contact Current: 2A
- Product Range: G6S Series
- Relay Mounting: Through Hole
- Coil Type: Latching Single Coil
- Relay Terminals: Solder
- Contact Voltage VAC: -
- Contact Voltage VDC: 30V
- Contact Material: Silver Gold
- Coil Resistance: 90ohm
- Approval Bodies: CSA
- Approval Category: UL Recognised
- Approvals & Standards: CSA, UL
- Coil Current: 33.3mA
- Coil Power Continuous: 100mW
- Coil Voltage VDC Nom: 3V
- Contact Current AC Max: 500mA
- Contact Current DC Max: 2A
- Contact Current Max: 2A
- Contact Current Min: 10µA
- Contact Resistance: 75mohm
- Contact Voltage AC Max: 125V
- Contact Voltage AC Nom: 125V
- Contact Voltage DC Max: 30V
- Contact Voltage DC Nom: 30V
- DC Coil Power: 100mW
- Dielectric Voltage Coil to Contact: 2000VAC
- Dielectric Voltage Contact to Contact: 1000VAC
- External Depth: 14.8mm
- External Height: 9.2mm
- External Length / Height: 9.2mm
- External Width: 7.3mm
- Insulation Resistance: 1000Mohm
- Insulation Resistance Voltage: 500VDC
