OMRON - H3DK-F AC/DC24-240 - Analogue Timer, H3DK-F, Flicker Off Start, Flicker On Start, 0.1 s, 1200 h, 8 Ranges, Solid State
- Product Range: H3DK-F Series
- Timer Functions: Flicker Off Start, Flicker On Start
- Time Min: 0.1s
- Time Max: 1200h
- No. of Timing Ranges: 8Ranges
- Timer Output: Solid State
- Supply Voltage Max: 240V
- Current Rating Nom: 5A
- Connection / Termination: Screw Terminals
- Adjustment Type: Screwdriver Slot
- Contact Configuration: SPDT
- Contact Current AC Max: 5A
- Contact Current DC Max: 5A
- Contact Voltage AC Max: 250V
- Contact Voltage DC Max: 24V
- Delay Time Range: 0.1s to 1200h
- External Depth: 100.2mm
- External Length / Height: 79mm
- External Width: 22.5mm
- Nom Input Voltage: 240V
- Operating Temperature Max: 55°C
- Operating Temperature Min: -20°C
- Relay Mounting: DIN Rail
- Supply Voltage Min: 24V
- Supply Voltage Range: 24V AC to 240V AC, 24V DC to 240V DC
- Timing Adjustment: Screwdriver Slot
- Type: Solid State
