IM03TS Relay, Signal, DPDT, 250VAC, 220VDC, 2A AXICOM - Te Connectivity

AXICOM - TE CONNECTIVITYUGS :IM03TS Code de commande:1175066

Prix:
Prix ​​promotionnel€6,03

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (47066 unité)

Documents et téléchargements

description

AXICOM - TE CONNECTIVITY - IM03TS - Signal Relay, 5 VDC, DPDT, 2 A, IM, Through Hole, Non Latching

  • Coil Voltage: 5VDC
  • Contact Configuration: DPDT
  • Contact Current: 2A
  • Product Range: IM Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: 250V
  • Contact Voltage VDC: 220V
  • Contact Material: Palladium Ruthenium
  • Coil Resistance: 178ohm
  • SVHC: No SVHC (15-Jan-2019)
  • Coil Power Continuous: 140mW
  • Coil Voltage VDC Nom: 5V
  • Contact Current Max: 2A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 220V
  • External Depth: 10mm
  • External Height: 5.65mm
  • External Width: 6mm
