TE CONNECTIVITY - 3-1462039-1 - Signal Relay, 12 VDC, DPDT, 2 A, IM Series, Surface Mount, Non Latching
- Coil Voltage: 12VDC
- Contact Configuration: DPDT
- Contact Current: 2A
- Product Range: IM Series
- Relay Mounting: SMD
- Coil Type: Non Latching
- Relay Terminals: Solder
- Contact Voltage VAC: 250V
- Contact Voltage VDC: 220V
- Contact Material: Palladium Ruthenium
- Coil Resistance: 2.88kohm
- Approval Bodies: EN, IEC
- Approval Category: UL Recognised
- Coil Power Continuous: 50mW
- Coil Voltage VDC Nom: 12V
- Contact Current AC Max: 2A
- Contact Current DC Max: 2A
- Contact Current Max: 2A
- Contact Resistance: 50mohm
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 220V
- DC Coil Power: 140mW
- Dielectric Voltage Coil to Contact: 1800V
- Dielectric Voltage Contact to Contact: 1000V
- External Depth: 10mm
- External Height: 5.65mm
- External Length / Height: 5.65mm
- External Width: 6mm
- Insulation Resistance: 1000Mohm
- Insulation Resistance Voltage: 500VDC
- No. of Pins: 8Pins
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Voltage Range: 10.2V to 43.2V
- Switch Power Max: 60W
