MC01003 Breadboard, 270 Pin multicomp

MULTICOMPUGS :MC01003 Code de commande:2503751

Prix:
Prix ​​promotionnel€2,74

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (34 unité)

Documents et téléchargements

description

MULTICOMP - MC01003 - Breadboard, 270 Pin, 8.5mm, x 46mm

  • Breadboard Type: Solderless Breadboard
  • Total Number of Tie Points: 270Tie Points
  • No. of Distribution Strips / Buses: 2Bus Strips
  • No. of Terminal Strips: 1 Terminal Strip
  • Board Dimensions (L x W) - Imperial: 3.3" x 1.8"
  • Board Dimensions (L x W) - Metric: 84mm x 46mm
  • SVHC: No SVHC (15-Jan-2018)
  • Board Connector / Footprint: Phosphor Bronze Nickel Plated Spring Clips
  • Board Material: ABS (Acrylonitrile Butadiene Styrene)
  • Board Thickness: 8.5mm
  • Board Type: Breadboard
  • External Depth: 8.5mm
  • External Height: 84mm
  • External Length / Height: 84mm
  • External Width: 46mm
  • Height: 84mm
  • Hole Diameter: 0.8mm
  • Hole Pitch: 2.54mm
  • Lead Diameter Max: 0.8mm
  • Lead Diameter Min: 0.3mm
  • Material: ABS
  • No. of Holes: 270
  • PCB Hole Diameter: 0.8mm
  • Pitch Spacing: 2.54mm
  • Row Pitch: 2.54mm
  • Type: Breadboard
