MULTICOMP PRO - MCSDC0604-331KU - Power Inductor (SMD), 330 µH, 270 mA, Unshielded, MCSDC0604, 6mm x 5.8mm x 4.8mm
- Inductance: 330µH
- RMS Current (Irms): 270mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): -
- Product Range: MCSDC0604 Series
- Power Inductor Case: 6mm x 5.8mm x 4.8mm
- DC Resistance Max: 2.25ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- External Depth: 5.8mm
- External Length / Height: 4.8mm
- External Width: 6mm
- Lead Spacing: 1.8mm
- No. of Pins: 2Pins
- Q Factor: 25
- Resonant Frequency: 1kHz
- Self Resonant Frequency Min: 3MHz
