description
MULTICOMP PRO - MCSDC0805-180MU - Power Inductor (SMD), 18 µH, 1.6 A, Unshielded, 2.6 A, MCSDC0805, 8mm x 7.8mm x 5.3mm
- Inductance: 18µH
- RMS Current (Irms): 1.6A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 2.6A
- Product Range: MCSDC0805 Series
- Power Inductor Case: 8mm x 7.8mm x 5.3mm
- DC Resistance Max: 0.1ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- External Depth: 7.8mm
- External Length / Height: 5.3mm
- External Width: 8mm
- Lead Spacing: 2.6mm
- No. of Pins: 2Pins
- Q Factor: 20
- Resonant Frequency: 1kHz
- Self Resonant Frequency Min: 15MHz
