MSS1038-224KLC Inductor, 220UH, 0.97A, 10%, Pwr, 4MHz COILCRAFT

COILCRAFTUGS :MSS1038-224KLC Code de commande:2288195

Prix:
Prix ​​promotionnel€3,52

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (16 unité)

Documents et téléchargements

description

COILCRAFT - MSS1038-224KLC - Power Inductor (SMD), 220 µH, 970 mA, Shielded, 720 mA, MSS1038

  • Inductance: 220µH
  • RMS Current (Irms): 970mA
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 720mA
  • Product Range: MSS1038 Series
  • Power Inductor Case: 10.2mm x 10mm x 3.8mm
  • DC Resistance Max: 0.756ohm
  • Inductance Tolerance: ± 10%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 4MHz
