Condensatoren
PC/HV/S/WF 1NF 1KV CAP, 1000PF, 1 KV, 20%, PP LCR COMPONENTS
Survolez l'image pour zoomer Cliquez sur l'image pour zoomer
PC/HV/S/WF 1NF 1KV CAP, 1000PF, 1 KV, 20%, PP LCR COMPONENTS

Pc/HV/S/WF 1nF 1kV Cap, 1000pf, 1 kV, 20%, PP LCR Components

LCR COMPONENTSUGS :PC/HV/S/WF 1NF 1KV Code de commande:9520287
Prix:
€3,57

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (180 unité)

Documents et téléchargements

Fiche Technique - FR

description

LCR COMPONENTS - PC/HV/S/WF 1NF 1KV - Power Film Capacitor, Metallized PP, Axial Leaded, 1000 pF, ± 20%, High Frequency, Through Hole

  • Capacitance: 1000pF
  • Voltage Rating: 1kV
  • Capacitor Dielectric Type: PP (Polypropylene)
  • Capacitance Tolerance: ± 20%
  • Product Range: PC/HV/S/WF Series
  • Capacitor Case Style: -
  • Capacitor Terminals: Axial Leaded
  • Lead Spacing: -
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 100°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Body Diameter: 9mm
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Mounting: Through Hole
  • Climatic Category: 40/85/56
  • External Length / Height: 20mm
  • Height: 20mm
  • Insulation Resistance: 100000Mohm
  • Lead Length: 40mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -55°C to +100°C
  • Power Factor: 0.0005
  • Power Factor Frequency: 1kHz
  • Pulse Rating: 1000V/µs
  • Temperature Coeff. -: -200ppm/°C
  • Temperature Coefficient: -200ppm/°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 1kV
  • Voltage Rating VAC: 350V
