ROHM - RN731VTE-17 - RF / Pin Diode, 7 ohm, SOT-323, 2 Pin
- Diode Configuration: -
- Resistance @ If: 7ohm
- Breakdown Voltage Vbr: -
- Diode Case Style: SOT-323
- No. of Pins: 2 Pin
- Total Capacitance Ct: -
- Forward Current If(AV): 50mA
- Operating Temperature Max: 125°C
- Product Range: RN731 Series
- Automotive Qualification Standard: -
- MSL: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Cd Max @ Vr F: 0.4pF
- Current If @ Vf: 50mA
- Diode Type: RF Pin
- Forward Voltage VF Max: 1V
- Junction Temperature Tj Max: 125°C
- No. of Pins: 2Pins
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +125°C
- Peak Forward Current: 50mA
- Power Dissipation Ptot Max: 100mW
- Repetitive Reverse Voltage Vrrm Max: 50V
- Termination Type: Surface Mount Device
