RT424F12 Relay, DPDT, 250VAC, 8A SCHRACK - Te Connectivity

SCHRACK - TE CONNECTIVITYUGS :5-1393243-4 Code de commande:1175085

Prix:
Prix ​​promotionnel€12,83

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (113 unité)

Documents et téléchargements

description

SCHRACK - TE CONNECTIVITY - 5-1393243-4 - Power Relay, DPDT, 12 VDC, 8 A, RT2, Through Hole, Latching Dual Coil

  • Contact Configuration: DPDT
  • Coil Voltage: 12VDC
  • Contact Current: 8A
  • Product Range: RT2 Series
  • Relay Mounting: Through Hole
  • Coil Type: Latching Dual Coil
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 240ohm
  • SVHC: No SVHC (07-Jul-2017)
  • Approval Bodies: CSA, VDE
  • Approval Category: UL Recognised
  • Approvals & Standards: CSA, UL, VDE
  • Coil Current: 33.3mA
  • Coil Voltage VDC Nom: 12V
  • Contact Current AC Max: 8A
  • Contact Voltage AC Max: 250V
  • Contact Voltage DC Max: 30V
  • DC Coil Power: 400mW
  • Dielectric Voltage Coil to Contact: 5kV
  • Dielectric Voltage Contact to Contact: 1kV
  • External Depth: 29mm
  • External Length / Height: 15.7mm
  • External Width: 12.7mm
  • Insulation Resistance: 10000Mohm
  • Lead Spacing: 5mm
  • Must Actuate Voltage: 8.4V
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -40°C
  • Relay Type: Power - General Purpose
  • Weight: 10g
