SD32X Data/Signal Line Protector, DIN Rail MTL Surge Technologies

MTL SURGE TECHNOLOGIESUGS :SD32X Code de commande:772471

Prix:
Prix ​​promotionnel€387,41

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (83 unité)

Documents et téléchargements

description

MTL SURGE TECHNOLOGIES - SD32X - Line Protector, 20 kA, 36 VAC, DIN Rail, CROUSE-HINDS MTL SD

  • No. of Poles: -
  • Peak Surge Current: 20kA
  • Continuing Operating Voltage Max: 36VAC
  • Suppressor Mounting: DIN Rail
  • Product Range: CROUSE-HINDS MTL SD Series
  • SVHC: No SVHC (17-Dec-2015)
  • Clamping Voltage: 32V
  • Connector Type: Terminal
  • External Depth: 99mm
  • External Length / Height: 102mm
  • External Width: 7mm
  • Forward Surge Current Ifsm Max: 400mA
  • Internal Resistance: 4.2ohm
  • Leakage Current: 5µA
  • Operating Frequency Max: 25kHz
  • Operating Temperature Max: 75°C
  • Operating Temperature Min: -30°C
  • Output Current: 400mA
  • Resistance: 2.2ohm
  • Response Time: 10ns
  • Suppressor Type: Data Line
  • Surge Current: 10kA
  • Voltage Rating: 32V
