SQMR7470RJ Res, 470R, 5%, 7w, Radial, Metal Film CGS - Te Connectivity

CGS - TE CONNECTIVITYUGS :SQMR7470RJ Code de commande:988005

Prix:
Prix ​​promotionnel€0,92

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (922 unité)

Documents et téléchargements

description

CGS - TE CONNECTIVITY - SQMR7470RJ - Through Hole Resistor, 470 ohm, SQ, 7 W, ± 5%, Radial Leaded, 500 V

  • Resistance: 470ohm
  • Product Range: SQ Series
  • Power Rating: 7W
  • Resistance Tolerance: ± 5%
  • Resistor Case Style: Radial Leaded
  • Voltage Rating: 500V
  • Resistor Element Material: Metal Film
  • Temperature Coefficient: ± 300ppm/°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • External Depth: 10mm
  • External Length / Height: 40mm
  • External Width: 14mm
  • Full Power Rating Temperature: 70°C
  • Lead Diameter: 0.8mm
  • Lead Length: 3.5mm
  • Lead Spacing: 5mm
  • Operating Temperature Max: 275°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +275°C
  • Overload Voltage: 1000V
  • Resistor Mounting: Through Hole
  • Temperature Coeff. +: 300ppm/°C
  • Temperature Coeff. -: 300ppm/°C
  • Tolerance +: 5%
  • Tolerance -: 5%
  • Voltage Rating V DC: 500V
