IMO PRECISION CONTROLS - SRZ-1CT-DL-24VDC - Automotive Relay, 24 VDC, 30 A, SPDT, Through Hole, Solder, SRZ
- Coil Voltage: 24VDC
- Contact Current: 30A
- Contact Configuration: SPDT
- Relay Mounting: Through Hole
- Relay Terminals: Solder
- Product Range: SRZ Series
- Contact Voltage DC Nom: 27V
- Coil Resistance: 360ohm
- Contact Material: Silver Tin Oxide
- SVHC: No SVHC (07-Jul-2017)
- Coil Voltage VDC Nom: 24V
- Contact Current DC Max: 30A
- Contact Current Max: 35A
- Contact Voltage DC Max: 27V
- DC Coil Power: 1.2W
- External Depth: 23mm
- External Height: 25.4mm
- External Length / Height: 25.4mm
- External Width: 15.5mm
- Insulation Resistance: 100Mohm
- Mechanical Life: 10,000,000 Operations
- No. of Mechanical Operations: 10000000
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Switch Current Max: 30A
- Switching Current Max: 30A
- Switching Power Max: 540W
