TRACO POWER - TEN 60-2413 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 60 W, 1 Output, 15 V, 4 A
- No. of Outputs: 1 Output
- Output Power Max: 60W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 4A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TEN60 Series
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 50.8mm
- Height: 10.2mm
- Depth: 50.8mm
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: IEC/EN 60950-1, UL/cUL 60950-1
- Approvals & Standards: IEC, UL
- Efficiency: 90%
- Isolation Voltage: 1.5kV
- No. of Outputs: 1Outputs
- Output Ripple Voltage pk-pk: 100mV
- Power Rating: 60W
- Supply Voltage: 24V
