TQ2SA-5V-Z Relay, Signal, DPDT, 30Vdc, 2A Panasonic

PANASONICUGS :TQ2SA-5V-Z Code de commande:2103612

Prix:
Prix ​​promotionnel€5,98

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (977 unité)

Documents et téléchargements

description

PANASONIC - TQ2SA-5V-Z - Signal Relay, 5 VDC, DPDT, 2 A, TQ, Surface Mount, Non Latching

  • Coil Voltage: 5VDC
  • Contact Configuration: DPDT
  • Contact Current: 2A
  • Product Range: TQ-SMD Series
  • Relay Mounting: SMD
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: -
  • Contact Voltage VDC: 30V
  • Contact Material: Silver
  • Coil Resistance: 178ohm
  • SVHC: No SVHC (07-Jul-2017)
  • Approvals & Standards: CSA, UL
  • Coil Current: 28.1mA
  • Coil Power Continuous: 140mW
  • Coil Voltage VDC Nom: 5V
  • Contact Current Max: 2A
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Nom: 30V
  • External Depth: 14mm
  • External Height: 5.6mm
  • External Width: 9mm
