XAP-02V-1 Housing, Crimp, Plug, 2.5mm, 2WAY JST (Japan Solderless Terminals)

JST (JAPAN SOLDERLESS TERMINALS)UGS :XAP-02V-1 Code de commande:7356064

Prix:
Prix ​​promotionnel€0,13

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (263075 unité)

Documents et téléchargements

description

JST (JAPAN SOLDERLESS TERMINALS) - XAP-02V-1 - Connector Housing, XA, Receptacle, 2 Ways, 2.5 mm, XA Series Contacts

  • Pitch Spacing: 2.5mm
  • No. of Contacts: 2Contacts
  • Gender: Receptacle
  • Product Range: XA Series
  • Contact Termination Type: -
  • No. of Rows: 1Rows
  • Contact Plating: -
  • Contact Material: -
  • SVHC: No SVHC (07-Jul-2017)
  • Colour: Natural (White)
  • Contact Resistance Max: 10mohm
  • Current Rating: 3A
  • External Depth: 6.9mm
  • External Width: 7.3mm
  • Flammability Rating: UL94V-0
  • For Use With: SXA Crimp Socket Contacts
  • Insulation Resistance: 1000Mohm
  • Material: Nylon 6.6
  • No. of Positions: 2Ways
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -25°C
  • Voltage Rating V DC: 250V
  • Voltage Rating VAC: 250V
  • Wire Size AWG Max: 20AWG
  • Wire Size AWG Min: 28AWG
  • Withstand Voltage: 1000VAC
